6.2.4 Status Menu
6.2.4.5.1 Status Menu Component (Channels)
Multi-channel unit:
In SELECT COMPONENT, select the chan-
nel to be viewed.
Multi-channel unit:
Press
left to enter SELECT COMPONENT,
to view the status for another channel.
Status..
Measurement..
Component..
Ch1
Component
Raw Signal1 109518.000
Raw Signal2 54321.000
Raw Signal 2.016
Concentration 1,984 %
Current Range Range 1
Statistics..
Secondary Variables..
Opens a submenu with measurement sta-
tistics for the selected channel; 6-113
Opens a submenu with information on se-
condary variables (pressure, ow, ...) of this
channel; 6-114
