Counter 1 Reset [6612]
Selection of the digital signal used as reset signal for counter
1. Counter 1 is cleared to 0 and held to 0 as long as reset
input is active (high).
Counter 1 High value [6613]
Sets counter 1 high limit value. Counter 1 value is clamped
to selected high limit value and the counter 1 output (C1Q)
is active (high) when the counter value equals the high value.
Counter 1 Low value [6614]
Sets counter 1 low limit value. Counter 1 output (C1Q) is
de-activated (low) when the counter value is equal or smaller
than the low value.
Counter 1 Decrement timer [6615]
Sets counter 1 automatic decrement timer value. The
counter 1 is decremented by 1 after elapsed decrement time
and if no new trigger has happened within the decrement
time. The decrement timer is reset to 0 at every counter 1
trig pulse.
Counter 1 Value [6619]
Parameter shows the actual value of counter 1.
Counter 2 [662]
Refer to description for Counter 1 [661].
Counter 2 Trigger [6621]
Function is identical to Counter 1 Trigger [6611].
Counter 2 Reset [6622]
Function is identical to Counter 1 Reset [6612].
NOTE: Reset input has top priority.
Default: Off
Selection: Same selections as “Digital Out 1 [541]”.
NOTE:
Value 0 means that counter output is always
true (high).
Default: 0
Range: 0 - 10000
NOTE:
Counter high value has priority so if high and low
values are equal then the counter output is de-
activated when the value is smaller than the low
value.
Default: 0
Range: 0 - 10000
Default: Off
Off 0 Off
1 - 3600 1 - 3600 1 - 3600 s
NOTE:
Counter 1 value is common for all parameter sets.
NOTE: The value is volatile and lost at power down.
Default: 0
Range: 0 - 10000
Default: Off
Selection: Same selections as Digital Out 1 [541].
Default: Off
Selection: Same selections as Digital Out 1 [541].
