182 CG Drives & Automation 01-7318-01r1
654 Timer2 T1 00:00:00
43456 170/105 4D80 19840 UInt, 1=1h UInt
10843457 170/106 4D81 19841 UInt, 1=1m UInt
43458 170/107 4D82 19842 UInt, 1=1s UInt
655 Timer2 T2 00:00:00
43459 170/108 4D83 19843 UInt, 1=1h UInt
10843460 170/109 4D84 19844 UInt, 1=1m UInt
43461 170/110 4D85 19845 UInt, 1=1s UInt
659 Timer2 Value 00:00:00
42924 168/83 4B6C 19308 UInt, 1=1h UInt
10942925 168/84 4B6D 19309 UInt, 1=1m UInt
42926 168/85 4B6E 19310 UInt, 1=1s UInt
660 Counters 109
661 Counter1 109
6611 C1 Trig Off 43571 170/220 4DF3 19955 UInt UInt 109
6612 C1 Reset Off 43572 170/221 4DF4 19956 UInt UInt 110
6613 C1 High Val 0 43573 170/222 4DF5 19957 Long, 1=1 EInt 110
6614 C1 Low Val 0 43574 170/223 4DF6 19958 Long, 1=1 EInt 110
6615 C1 DecTimer Off 43575 170/224 4DF7 19959 Long, 1=1s EInt 110
6619 C1 Value 0 42927 168/86 4B6F 19311 UInt, 1=1 UInt 110
662 Counter2 110
6621 C2 Trig Off 43581 170/230 4DFD 19965 UInt UInt 110
6622 C2 Reset Off 43582 170/231 4DFE 19966 UInt UInt 110
6623 C2 High Val 0 43583 170/232 4DFF 19967 Long, 1=1 EInt 111
