80 Functional Description Emotron AB 01-4429-01r2
User-defined Unit [323]
This menu is only displayed if User is selected in menu
[322]. The function enables the user to define a unit with six
symbols. Use the Prev and Next key to move the cursor to
required position. Then use the + and - keys to scroll down
the character list. Confirm the character by moving the cur-
sor to the next position by pressing the Next key.
Example:
Create a user unit named kPa.
1. When in the menu [323] press Next to move the cursor
to the right most position.
2. Press the + key until the character k is displayed.
3. Press Next.
4. Then press the + key until P is displayed and confirm
with Next.
5. Repeat until you have entered kPa.
Communication information
When sending a unit name you send one character at a time
starting at the right most position.
Character
No. for serial
comm.
Character
No. for serial
comm.
Space 0 m 58
0–9 1–10 n 59
A11ñ60
B12o61
C13ó62
D14 ô63
E15p64
F16q65
G17 r 66
H18 s 67
I19t68
J20u69
K21 ü70
L22v71
M23 w 72
N24 x 73
O25 y 74
P26z75
Q27 å76
R28ä77
S29ö78
T30! 79
U31¨80
Ü32#81
V33$82
W34 %83
X35&84
Y36· 85
Z37( 86
Å38) 87
Ä39*88
Ö40 +89
a41, 90
á42- 91
b43. 92
c44/93
d45: 94
e46; 95
é47<96
ê48=97
ë49>98
f50?99
g51@100
h52^101
i53_102
í54
°
103
j55
2
104
k56
3
105
l57
Default: No characters shown
Modbus Instance no/DeviceNet no:
43304
43305
43306
43307
43308
43309
Profibus slot/index
169/208
169/209
169/210
169/211
169/212
169/213
Fieldbus format UInt
Modbus format UInt
Character
No. for serial
comm.
Character
No. for serial
comm.
