Guide to the Control Panel
Note:
❏ Control panel design varies depending on location.
❏ Although the control panel design and what displayed on the LCD screen such as menu names and option names may
differ from your actual product, the method of operation is the same.
WF-4640 Series/WF-5690 Series
WF-4630 Series/WF-5620 Series
Buttons/Lights Function
a
Turns the product on or off. The power light turns on when the product is on.
Flashes when the product is printing/copying/scanning/faxing, replacing an ink cartridge,
charging ink, or cleaning the print head.
b
Returns to the top menu.
c
Interrupts the current print or copy job and allows you to perform a different print or copy job.
Press this button again to restart the job that has been paused.
d
Resets your settings to user default settings. If user default settings have not been made, resets
to the factory default.
e
y
Stops the current operation.
User’s Guide
Getting to Know Your Product
19
