Epson DS-790WN

To Next Page

To Previous Page

Use Destination

(Server)

Protocol Port

Number

Searching WSD scanner Scanner WS-Discovery (UDP) 3702

Forwarding the scan data from an

application

Scanner Network Scan (TCP) 1865

Collecting the job information when push

scanning from an application

Scanner Network Push Scan 2968

Web Cong Scanner HTTP(TCP) 80

HTTPS(TCP) 443

Dimensions and Weight Specications

Dimensions

Storage (Unit: mm (inches))

Scanning (Unit: mm (inches))

Technical Specications

Dimensions and Weight Specications

239
