Epson LX-810 User Guide

Using Continuous Paper
The push tractor built into your printer can handle paper widths
from 101 mm (4.0 inches) to 254 mm (10.0 inches).
Positioning your continuous paper supply
Here are three ways to position your printer and supply of
continuous paper.
Make sure you align your paper supply with the paper loaded in
the tractor so that the paper feeds smoothly into the printer.
Loading continuous paper
1. Make sure the printer is turned off. Then remove the paper
guide and pull the paper-release lever forward to the
continuous paper position.
2. Release the sprocket units by pulling the sprocket locks
forward.
2-4
Paper Handling

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
