Epson LX-810 User Guide

Commands Arranged by Topic
ASCII
Dec. Hex. Description
HT
9 09
Tab Horizontally
ESC D nn
68 44
Set Horizontal Tabs
Up to 32 tabs (l-137) entered in
ascending order
Terminated by 0
Overall printing style
ASCII
Dec. Hex. Description
ESC x n
120 78
Select NLQ or Draft
1:NLQ
0:Draft
ESC k n
107 6B
Select NLQ Font
0:Roman
1:Sans Serif
ESC ! n 33 21
Master Select
To find the value of n, add together
the numbers of the typestyles you
want to combine from the list below:
10 cpi: 0 decimal, 00 hex
12 cpi: 1, 01
condensed: 4, 04
emphasized: 8, 08
double-strike: 16, 10
double-width: 32, 20
italics: 64, 40
underline: 128, 80
Print size and character width
ASCII Dec. Hex. Description
ESC P 80 50
Select 10 cpi
8-6
Command Summary

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
