Epson LX-810 User Guide

Printable area
13 mm (0.51 inch) or more (both sides) when the 101 mm to
242 mm (4 to 9.5 inch) width paper is used. 26 mm (1.02
inch) or more (left side) and 24 mm (0.94 inch) or more
(right side) when the 254 mm (10 inch) width paper is used.
Envelope
8.5 mm (0.33")
or more
22 mm (0.87”)
3 mm (0.12")
or more
or more
Paper thickness:
Single sheet
0.065 to 0.140 mm (0.0025 to 0.0055”)
Continuous paper
0.065 to 0.250 mm (0.0025 to 0.0098”)
Roll paper
0.070 to 0.090 mm (0.0028 to 0.0035”)
Envelope
0.160 to 0.520 mm (0.0063 to 0.0197”)
Label
0.160 to 0.190 mm (0.0063 to 0.0075”
including the base sheet)
7-4
Technical Specification

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
