Epson RC700 Series - Typical Input Circuit Application 1

Functions 13. I/O Connector
146 RC700 Series Rev.3
13.1.1 Typical Input Circuit Application 1
1 Input No.0～7 common
2 Input No.0
3 Input No.1
4 Input No.2
5 Input No.3
6 Input No.4
7 Input No.5
8 Input No.6
9 Input No.7
I/O-1
(s
ame
)
same
GND +DC
18 Input No.8～15 common
19 Input No.8
20 Input No.9
34 Input No.16～23 common
same
26 Input No.15
42 Input No.23
35 Input No.16
36 Input No.17
