Epson RC700 Series Original Instructions

Installation 2. Installation
48 RC700 Series Rev.3
2.7.2 Power Supply
Specification
Ensure that the power meets the following specifications.
Item
Specification
Voltage
200 to 240 VAC
(Input voltage should be with in ±10 % of the rated voltage.)
Phase
Single phase
Frequency
50/60 Hz
Momentary
Power Interrupt
10 ms or less
Rated Capacity
Maximum : 2.5 kVA
Actual power consumption depends on the model, motion, and
load of the Manipulator.
For approximate power consumption of each model, refer to the
following values.
RC700 / RC700-A
C4 : 1.7 kVA
C8 : 2.5 kVA
C12 : 2.5 kVA
N2 : 0.6 kVA
N6 : 2.2 kVA
G1 : 0.5 kVA
G3 : 1.1 kVA
G6 : 1.5 kVA
G10 : 2.4 kVA
G20 : 2.4 kVA
RS3 : 1.2 kVA
RS4 : 1.4 kVA
RC700DU / RC700DU-A
C4 : 1.7 kVA
C8 : 2.5 kVA
N6 : 2.2 kVA
G1 : 0.5 kVA
G3 : 1.1 kVA
G6 : 1.5 kVA
G10 : 2.4 kVA
G20 : 2.4 kVA
RS3 : 1.2 kVA
RS4 : 1.4 kVA
Refer to the Manipulator manual for rated capacity of the
Manipulator motor.
Max. load current
Max : 12.5 A
Actual Value depends on the model, motion, and load of the
Manipulator.
For approximate power consumption of each model, refer to the
following values.
RC700 / RC700-A
C4 : 8.5 A
C8 : 12.5 A
C12 : 12.5 A
N2 : 3.0 A
N6 : 11.0 A
G1 : 2.5 A
G3 : 5.5 A
G6 : 7.5 A
G10 : 12.0 A
G20 : 12.0 A
RS3 : 6.0 A
RS4 : 7.0 A
RC700DU / RC700DU-A
C4 : 8.5 A
C8 : 12.5 A
N6 : 11.0 A
G1 : 2.5 A
G3 : 5.5 A
G6 : 7.5 A
G10 : 12.0 A
G20 : 12.0 A
RS3 : 6.0 A
RS4 : 7.0 A

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
