Epson RC700 Series Original Instructions

Functions 15. R-I/O Connector
RC700 Series Rev.3 165
15.2 Pin Assignments
CAUTION

When using R-I/O
connector, be careful of the following points. If you use the
R-
I/O connector without meeting the necessary conditions, it may cause the
system failure and/or safety problems.
- Use a shielded cable and route the cables as far from the surrounding
noise sources as possible.
For details, refer to 3.5 Noise Countermeasures.
- Make sure to check the cable routing before turning ON the power
supply.
15.2.1 Pin Assignments for Control Unit
Pin No.
Signal Name
9 INPUT No24-1
10 INPUT No24-2
11 INPUT No25-1
12 INPUT No25-2
1 to 8, 13 to 15*
Not Used
* For the pins 1 to 8 and 13 to 15, do not connect anything.
Connector
Standard
R-I/O Connector (Controller side)
D-sub 15 male pin
Screwlock #4 - 40
15.2.2 Pin Assignments for Drive Unit
Pin No.
Signal Name
(Drive Unit 1)
Signal Name
(Drive Unit 2)
Signal Name
(Drive Unit 3)
1 INPUT No.56-1 INPUT No.280-1 INPUT No.312-1
2
INPUT No.56-2
INPUT No.280-2
INPUT No.312-2
3 INPUT No.57-1 INPUT No.281-1 INPUT No.313-1
4 INPUT No.57-2 INPUT No.281-2 INPUT No.313-2
5~15
*
Not Used
* For the pins 5 to 15 , do not connect anything.
Connector
Standard
R-I/O Connector
(Drive Unit side)
D-sub 15 male pin
Screwlock #4 - 40

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
