Epson RC700 Series Original Instructions

Functions 15. R-I/O Connector
164 RC700 Series Rev.3
15.1.2 Input Circuit for Drive Unit
The following two types of w
iring are available in the input circuit for Drive Unit.
Typical Input Circuit Application 1
R-I/O
Input No.56-1
Input No.56-2
Input No.57-1
Input No.57-2
GND +24V
9
10
11
12
Typical Input Circuit Application 2
R-I/O
Input No.56-1
Input No.56-2
Input No.57-1
Input No.57-2
GND +24V
9
10
11
12

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
