Rev. A Product Overview Appendix D-49
TM-H6000/H6000P Service Manual
Confidential
P10/D8 79 External data bus D8
10
P11/D9 80 External data bus D9
10
P12/D10 81 External data bus D10
10
P13/D11 82 External data bus D11
10
P14/D12 83 External data bus D12
10
P15/D13 84 External data bus D13
10
P16/D14 85 External data bus D14
10
P17/D15 86 External data bus D15
10
DVSS 87 GND
DVCC 88 VCC
DVSS 89 GND
P67/A23 90 External address bus A23
10
P66/A22 91 External address bus A22
10
P65/A21 92 External address bus A21
10
P64/A20 93 External address bus A20
10
P63/A19 94 External address bus A19
10
P62/A18 95 External address bus A18
10
P61/A17 96 External address bus A17
10
P60/A16 97 External address bus A16
10
DVCC 98 VCC
P57/A15 99 External address bus A15
10
P56/A14 100 External address bus A14
10
P55/A13 101 External address bus A13
10
P54/A12 102 External address bus A12
10
P53/A11 103 External address bus A11
10
P52/A10 104 External address bus A10
10
P51/A09 105 External address bus A9
10
P50/A08 106 External address bus A8
10
DVSS 107 GND
P47/A07 108 External address bus A7
10
P46/A06 109 External address bus A6
10
P45/A05 110 External address bus A5
10
P44/A04 111 External address bus A4
10
P43/A03 112 External address bus A3
10
P42/A02 113 External address bus A2
10
TableD-7 CPU terminals and functions
Port (Terminal) Pin Description Circuit Signal I/O I/O Definition
Name No. Name
HL
To Next Page
