Disassembly and Assembly 2-34 Rev. A
Confidential
27. Insert supporting plate A into the lower case.
28. Cut the bar of the upper case.
29. Assemble the upper case and the table holder to the lower case.
30. Place thermal sheet onto the M-T6000 rack.
31. Connect the thermal head FFC to the M-T6000.
32. Attach the control panel unit to the front case.
33. Attach the clamp to the mechanism assembly.
34. Connect the control panel unit cable to the control panel circuit board assembly.
35. Assemble the front case to the mechanism assembly with two screws. Align and the front
case to the nibs on the right side. Tighten one screw B-0, 3 ✕ 10 in the screw hole on the right
side and one screw 4 ✕ 20 on the left side.
To Next Page
