TM-T88III series
Specification
(STANDARD)
B
ESC S
[Name] Select standard mode
[Format] ASCII ESC S
Hex 1B 53
Decimal 27 83
[Description] Switches from page mode to standard mode.
[Details]
• This command is effective only in page mode.
• Data buffered in page mode are cleared.
• This command sets the print position to the beginning of the line.
• The printing area set by ESC W are initialized.
• This command switches the settings for the following commands (in which the values can be
set independently in standard mode and page mode) to those for standard mode:
① Set right-side character spacing: ESC SP, FS S
② Select default line spacing: ESC 2, ESC 3
• The following commands are enabled only to set in standard mode.
① Set printing area in page mode: ESC W
② Select print direction in page mode: ESC T
• The following commands are ignored in standard mode.
① Set absolute vertical print position in page mode: GS $
② Set relative vertical print position in page mode: GS \
• Standard mode is selected automatically when power is turned on, the printer is reset, or
command
ESC @ is used.
[Reference]
FF, ESC FF, ESC L

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
