Confidential
EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
B
52 51
TM-T88III series
Specification
(STANDARD)
3.3 Switches and Buttons
3.3.1 Power Button
The power button (a rocker switch) located on the lower right front of the printer turns the power on or
off.
NOTE: Turn on the power only after connecting the power supply.
3.3.2 Panel Buttons
1) FEED button: Non-locking push button
[Function] If you push this button once and release it, the printer feeds paper for one line based
on the line spacing set by ESC 2 and ESC 3. However, paper feeding using the
FEED button cannot be performed under the following conditions:
The paper roll end sensor detects a paper end
When the printer cover is open.
If you push this button when the printer is in the macro execution standby state, the
defined macro is executed.
During self-test printing, you can stop the self test temporarily by pressing this button
and restart it by pressing the button again.
NOTE: This button is disabled by ESC c 5.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson TM-T88III series and is the answer not in the manual?

Epson TM-T88III series Specifications

General IconGeneral
Print MethodThermal line printing
Resolution180 dpi
Paper Width79.5 ± 0.5 mm
Print Speed150 mm/sec
InterfaceUSB, Serial, Parallel, Ethernet
AutocutterPartial cut
Dimensions145 x 195 x 148 mm (W x D x H)
Power24 V DC ±10%
Power SupplyExternal power supply (depending on model)
Paper Thickness0.06 to 0.085 mm
