TM-T88III series
Specification
(STANDARD)
3.5 Self-test
1) The printer has a self-test function that checks the following:
• Control circuit functions
• Printer mechanisms
• Print quality
• Control software version
• DIP switch settings
2) Starting the self-test
To start the self-test on a paper roll, hold down the FEED button and turn on the printer with the
cover closed, then the current printer status (*1) is printed.
(*1) • Control software version
• DIP switch settings
3) Self-test standby state
After printing the current printer status, the printer prints the message "Self-test printing. Please
press FEED button." The PAPER OUT LED indicator blinks and the printer enters the test
printing (*2) standby state. Press the FEED button to start test printing.
(*2) • A rolling pattern using only the built-in character set
• A partial cut after completing the test printing
4) Ending the self-test
After a number of lines are printed, the printer indicates the end of the self-test by printing "***
completed ***", initializes, and goes to the standard mode (refer to Section 3.12, Page Mode).

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
