Epson TM-T88III series User Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
123 122
TM-T88III series
Specification
(STANDARD)
B
GS B n
[Name] Turn white/black reverse printing mode
[Format] ASCII GS B
n
Hex 1D 42
n
Decimal 29 66
n
[Range] 0
≤ n ≤ 255
[Description] Turns on or off white/black reverse printing mode.
• When the LSB of n is 0, white/black reverse mode is turned off.
• When the LSB of n is 1, white/black reverse mode is turned on.
[Details]
• Only the lowest bit of n is valid.
• This command is available for built-in characters and user-defined characters.
• When white/black reverse printing mode is on, it also applied to character spacing set by ESC
SP
.
• This command does not affect bit image, user-defined bit image, bar code, HRI characters,
and spacing skipped by
HT, ESC $, and ESC \.
• This command does not affect the space between lines.
• White/black reverse mode has a higher priority than underline mode. Even if underline
mode is on, it is disabled (but not canceled) when white/black reverse mode is selected.
[Default]
n = 0
GS H n
[Name] Select printing position for HRI characters
[Format] ASCII GS H
n
Hex 1D 48 n
Decimal 29 72 n
[Range] 0 ≤ n ≤ 3, 48 ≤ n ≤ 51
[Description] Selects the printing position of HRI characters when printing a bar code.
n selects the printing position as follows:
n Printing position
0, 48 Not printed
1, 49 Above the bar code
2, 50 Below the bar code
3, 51 Both above and below the bar code
[Details] • HRI indicates Human Readable Interpretation.
• HRI characters are printed using the font specified by GS f.
[Default]
n = 0
[Reference]
GS f, GS k

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
