TM-T88III series
Specification
(STANDARD)
B
GS \ nL nH
[Name] Set relative vertical print position in page mode
[Format] ASCII GS \
nL nH
Hex 1D 5C nL nH
Decimal 29 92 nL nH
[Range] 0 ≤ nL ≤ 255
0
≤ nH ≤ 255
[Description] Sets the relative vertical print starting position from the current position in page mode.
• This command sets the distance from the current position to [(nL + nH × 256)
× vertical or horizontal motion unit].
[Details]
• This command is ignored unless page mode is selected.
• When pitch N is specified to the movement downward:
nL + nH × 256 = N
When pitch N is specified to the movement upward (the negative direction), use the
complement of 65536.
When pitch
N is specified to the movement upward:
nL + nH × 256 = 65536 - N
• Any setting that exceeds the specified printing area is ignored.
• This command function as follows, depending on the print starting position set by ESC T:
① When the starting position is set to the upper left or lower right of the printing, the vertical
motion unit (
y) is used.
② When the starting position is set to the upper right or lower left of the printing area, the
horizontal motion unit (
x) is used.
• The horizontal and vertical motion unit are specified by GS P.
• The GS P command can change the horizontal (and vertical) motion unit. However, the
value cannot be less than the minimum horizontal movement amount, and it must be in even
units of the minimum horizontal movement amount.
[Reference]
ESC $, ESC T, ESC W, ESC \, GS $, GS P, 3.12 Page Mode

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
