TM-T88III series
Specification
(STANDARD)
B
• If the width set for the printing area is less than the width of one character, when the
character data is developed, the following processing is performed:
① The printing area width is extended to the right to accommodate one character.
Printable area
A
Left margin Extended to right
Printing area width set by nL and nH
② If the printing area width cannot be extended sufficiently, the left margin is reduced to
accommodate one character.
Printable area
A
Left margin ② Reduce left margin ① Extended to right
③ If the printing area width cannot be extended sufficiently, the right space is reduced.
• If the width set for the printing area is less than one line in vertical, the following processing is
performed only on the line in question when data other than character data (e.g., bit image,
user-defined bit image) is developed:
① The printing area width is extended to the right to accommodate one line in vertical for the
bit image within the printable area.
② If the printing area width cannot be extended sufficiently, the left margin is reduced to
accommodate one line in vertical.
• The commands which set the printing area width for bit image printing and its minimum
widths are as follows:
• Bit image (ESC ∗
∗∗
∗):
Single density mode = 2 dots
Double density mode = 1 dot
• Downloaded bit image (GS /):
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
• NV bit image (FS p):
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
• Raster bit image (GS v 0):
Double width mode or Quadruple mode = 2 dots
Normal mode or Double-height mode = 1 dot
[Default]
nL = 0, nH = 2
[Reference]
GS L, GS P
