TM-T88III series
Specification
(STANDARD)
B
1.7 Printing and Cutting Positions
Paper feed direction
[ Units: mm (All the numeric values are typical.) ]
Center of the print dotline
Auto-cutter blade position
Manual-cutter position
14.8
26.3
Figure 1.7.1 Printing and Cutting Positions
NOTE: Numeric values used here are typical values; the values may vary slightly as a result of
paper slack or variations in the paper. Take the notice into account when setting the cutting
position of the auto-cutter.
1.8 Internal Buffer
1) Receive buffer selectable as 45 bytes or 4 KB using the DIP switch.
2) User-defined buffer (both for user-defined characters and user-defined bit images): 12 KB
3) Macro buffer: 2 KB
4) NV (Non-volatile) bit image buffer: 256 KB
5) NV user memory: 1 KB
Approx. 29
Approx. 15
