3.3.3 DIP Switches
3.3.3.1 Serial interface specification
1) DIP switch 1: 8 switches
Table 3.3.1 DIP Switch 1
SW 1 Function ON OFF
1 Data reception error Ignored Prints '?'
2 Receive buffer capacity 45 bytes 4K bytes
3 Handshaking XON/XOFF DTR/DSR
4 Word length 7 bits 8 bits
5 Parity check Yes No
6 Parity selection Even Odd
7 Transmission speed selection Refer to Table 3.3.2
8
Table 3.3.2 Transmission Speed
Transmission Speed (bps) SW 1-7 SW 1-8
38400 ON ON
4800 OFF ON
9600 ON OFF
19200 OFF OFF
bps: bits per second
