TM-T88III series
Specification
(STANDARD)
B
FS p n m
[Name] Print NV bit image
[Format] ASCII FS p
n m
Hex 1C 70 n m
Decimal 28 112 n m
[Range] 1 ≤ n ≤ 255
0
≤ m ≤ 3 , 48 ≤ m ≤ 51
[Description] Prints a NV bit image
n using the mode specified by m.
m Mode Vertical Dot Density Horizontal Dot Density
0, 48 Normal 180 dpi 180 dpi
1, 49 Double-width 180 dpi 90 dpi
2, 50 Double-height 90 dpi 180 dpi
3, 51 Quadruple 90 dpi 90 dpi
[dpi: dots per 25.4 mm {1"}]
• n is the number of the NV bit image (defined using the FS q command).
• m specifies the bit image mode.
[Details]
• NV bit image means a bit image which is defined in a non-volatile memory by
FS q and printed by FS p.
• This command is not effective when the specified NV bit image has not been defined.
• In standard mode, this command is effective only when there is no data in the print buffer.
• In page mode, this command is not effective.
• This command is not affected by print modes (emphasized, double-strike, underline,
character size, white/black reverse printing, or 90
° rotated characters, etc.), except
upside-down printing mode.
• If the printing area width set by GS L and GS W for the NV bit image is less than one vertical
line, the following processing is performed only on the line in question. However, in NV bit
image mode, one vertical line means 1 dot in normal mode (
m=0, 48) and in double-height
mode (
m=2, 50), and it means 2 dots in double-width mode (m=1, 49) and in quadruple mode
(
m=3, 51).
① The printing area width is extended to the right in NV bit image mode up to one line
vertically. In this case, printing does not exceed the printable area.
② If the printing area width cannot be extended by one line vertically, the left margin is
reduced to accommodate one line vertically.
• If the downloaded bit-image to be printed exceeds one line, the excess data is not printed.
• This command feeds dots (for the height n of the NV bit-image) in normal and double-width
modes, and (for the height
n × 2 of the NV bit-image) in double-height and quadruple modes,
regardless of the line spacing specified by
ESC 2 or ESC 3.
• After printing the bit image, this command sets the print position to the beginning of the line
and processes the data that follows as normal data.
[References]
ESC ∗
∗∗
∗, FS q, GS /, GS v 0
