Epson TM-T88III series User Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
128 127
TM-T88III series
Specification
(STANDARD)
B
①
①①
① GS V m ②
②②
② GS V m n
[Name] Select cut mode and cut paper
[Format]
① ASCII GS V m
Hex 1D 56 m
Decimal 29 86 m
② ASCII GS V m n
Hex 1D 56 m n
Decimal 29 86 m n
[Range] ① m = 1, 49
② m = 66, 0 ≤ n ≤ 255
[Description] Selects a mode for cutting paper and executes paper cutting. The value of
m selects the mode
as follows:
m Print mode
1, 49 Partial cut (one point left uncut)
66
Feeds paper (cutting position + [
n × (vertical motion unit)]), and cuts the paper
partially (one point left uncut).
[Details for ① and ②]
• This command is effective only processed at the beginning of a line.
[Details for
①]
• Only the partial cut is available; there is no full cut.
[Details for
②]
• When n = 0, the printer feeds the paper to the cutting position and cuts it.
• When n ≠ 0, the printer feeds the paper to (cutting position + [n × vertical motion unit]) and
cuts it.
• The horizontal and vertical motion unit are specified by GS P.
• The paper feed amount is calculated using the vertical motion unit (y). However, the value
cannot be less than the minimum horizontal movement amount, and it must be in even units
of the minimum horizontal movement amount.

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
