TM-T88III series
Specification
(STANDARD)
B
ESC { n
[Name] Turns on/off upside-down printing mode
[Format] ASCII ESC {
n
Hex 1B 7B n
Decimal 27 123 n
[Range] 0 ≤ n ≤ 255
[Description] Turns upside-down printing mode on or off.
• When the LSB of n is 0, upside-down printing mode is turned off.
• When the LSB of n is 1, upside-down printing mode is turned on.
[Details]
• Only the lowest bit of n is valid.
• This command is enabled only when processed at the beginning of a line in standard mode.
• When this command is input in page mode, the printer performs only internal flag operations.
• This command does not affect printing in page mode.
• In upside-down printing mode, the printer rotates the line to be printed by 180° and then prints
it.
[Default]
n = 0
[Example]
ABCDE
01234
F
5
ABCDE
01234
F
5
Paper feed direction
When upside-down printing
mode is selected
When upside-down printing
mode is not selected
