TM-T88III series
Specification
(STANDARD)
B
FS W n
[Name] Turn quadruple-size mode on/off for Kanji characters
[Format] ASCII FS W
n
Hex 1C 57
n
Decimal 28 87
n
[Range] 0
≤ n ≤ 255
[Description] Turns quadruple-size mode on or off for Kanji characters.
• When the LSB of n is 0, quadruple-size mode for Kanji characters is turned off.
• When the LSB of n is 1, quadruple-size mode for Kanji characters is turned on.
[Notes]
• Only the lowest bit of n is valid.
• In quadruple-size mode, the printer prints the same size characters as when double-width
and double-height modes are both turned on.
• When quadruple-size mode is turned off using this command, the following characters are
printed in normal size.
• When some of the characters on a line are different in height, all the characters on the line
are aligned at the baseline.
• FS ! or GS ! can also select and cancel quadruple-size mode by selecting double-height and
double-width modes, and the setting of the last received command is effective.
[Default]
n = 0
[Reference]
FS !, GS !
App.1

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
