TM-T88III series
Specification
(STANDARD)
B
Drawer kick-out connector status (
n = 2, 50):
Bit Off/On Hex Decimal Function
0 Off 00 0 Drawer kick-out connector pin 3 is LOW.
On 01 1 Drawer kick-out connector pin 3 is HIGH.
1-3 - - - Undefined.
4 Off 00 0 Not used. Fixed to Off.
5, 6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
[Reference] DLE EOT, GS a, Appendix G
