Epson TM-T88III series User Manual

Confidential
EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
69 68
TM-T88III series
Specification
(STANDARD)
B
(5) Printable area
The maximum range within which printing is possible under the printer specifications. The
printable area for this printer is as follows:
① The length of the horizontal direction in standard mode:
approximately 72.2 mm {512/180"}
② The length of the horizontal direction in page mode:
approximately 72.2 mm {512/180"}
③ The length of the vertical direction in page mode: approximately 117.3 mm {1662/360"}
(6) Printing area
Printing range is set by the command. It must be printing area ≤ printable area.
(7) Ignore
The state in which all codes, including parameters, are read in and discarded, and nothing
happens.
(8) Inch
A unit of length. One inch is 25.4 mm.
(9) MSB
Most Significant Bit
(10) LSB
Least Significant Bit
(11) Base line
Standard position when character data is stored in the print buffer.
Normal character in standard mode and page mode:
A
18 dots
8 dots
Line spacing
(default)
B
A
48 dots
Line spacing (default)
Base line
Base line
21 dots
10 dots
B
A y
Base line
9 dots
A
Rotated character in standard mode (only when font A is selected):
∗1
∗1. When font A (12×24 dots) is selected,
this height is for 21 dots.
When font B (9×17 dots) is selected, this
height is for 16 dots.

Epson TM-T88III series Specifications

General

Print Method	Thermal line printing
Resolution	180 dpi
Paper Width	79.5 ± 0.5 mm
Print Speed	150 mm/sec
Interface	USB, Serial, Parallel, Ethernet
Autocutter	Partial cut
Dimensions	145 x 195 x 148 mm (W x D x H)
Power	24 V DC ±10%
Power Supply	External power supply (depending on model)
Paper Thickness	0.06 to 0.085 mm
