1.5.2 Setting fixed options
Certain settings are defined by selecting an option from a list.
The list might look like this:
MIG/MAG
MMA
TIG
CARBON, ArcAir
MIG SUPERPULSE
Here the cursor is on the line for MIG/MAG. If you press the ENTER key now, you
will select the M IG/MAG option.
However, if you want to select another option you move the cursor to the line in
question by moving up or down using the arrow keys.
You then press the ENTER key.
If you want to exit the list without making a selection, press the QUIT key.
Some settings have so m any options that they cannot all be displayed in the list at
the same time. An arrow at the top or bottom of a list indicates that more options will
become visible if you scroll up or down using the arrow keys.
1.5.3 ON/OFF or YES/NO settings
For some functions you can set the values ON or OFF or YES or NO. T he synergic
function for MIG/MAG welding and MMA welding is one example of such a function.
The ON/OFF or YES/NO settings can be defined in one of two ways:
You can select ON or OFF or YES or NO from a list of options as described above.
You can also use the plus/minus keys to define ON/OFF or YES/NO (applies to
certain functions).
S + (plus) = ON or YES
S --(minus)=OFForNO
1.6 ENTER and QUIT
The two ”soft” keys on the far right are primarily used for ENTER and QUIT but are
sometimes used for other functions.
S By pressing ENTER you confirm the selected option in a menu or list.
S By pressing QUIT you return to the previous menu or display.
GB
