ESAB Aristo U8 - 8.5 Copying Weld Data

-- 3 4 --
bi09d1e2
The following text box appears briefly:
RECALLED DATA SET NO. 5
Return to the memory menu by pressing the QUIT key.
This icon in the measure image shows which
memory position has been recalled.
8.5 Copy
This is how you copy the content of a weld data setting to a new memory position:
MEMORY FUNCTIONS -- STORED DATA SETS
Press the COPY key.
5
STORE DELETE RECALL COPY QUIT
The most recently saved data set is automatically selected. If more than one data set
is stored, you can move the cursor between them using the arrow left and arrow right
keys. We are now going to copy the content of memory position 5 to position 50.
By scrolling using the plus/minus keys, you can define the memory position to which
you want to copy.
COPY WELD DATA NO. 5 TO NO. 50
Scroll to number 50 using
the plus key and press
ENTER.
5
" DIP/SPRAY, Fe, CO2, 1.2 mm
QUIT ENTER
