10.8.4 Explanation of digits in the ChangeStatus column:
0 Neither the welding schedule, wire speed nor voltage have been changed since
the end of the previous weld.
1 Wire speed and/or voltage changed before welding started.
2 Wire speed and/or voltage changed during welding.
3 Wire speed and/or voltage changed before and during welding (1+2)
4 New welding schedule requested during weld in progress.
5 Does not occur
6 New welding schedule requested and wire speed and/or voltage changed during
weld in progress (4+2)
7 Does not occur
10.8.5 Description of welding data sched u le
Each welding data schedule can have a short description. Under the ”Setting” and ”Edit description”
menus, the last requested welding data schedule can be given a description of 40 characters via the
built--in keyboard. The current description can also be modified or deleted.
If the requested schedule has a description, this is shown in the ”Memory”, ”Measure” and ”Remote”
windows instead of the welding data parameters which are otherwise displayed.
11 WELD DATA SETS
Main menu ----> Auxiliary functions menu
To enable you to use this function fully, insert a compact flash card into the controller
(see the 10 ”File manager”. chapter).
Please note that PC cards used in previous U8s can also be used for storage and
recall of welding data. Consequently, welding data saved on PC cards n eed not be
lost with this m odification of the U8. The one requirement is that the U8 used for
storage must not have su c h an old software version that it causes compatibility
problems. Data stored using a PUA cannot be recalled on this controller.
11.1 Example: Saving welding data on a memory card
AUXILIARY FUNCTIONS
Highlight welding data
configurations. Press
STORE.
FILE MANAGER
WELD DATA SETS
CONFIGURATION
QUALITY FUNCTIONS
PRODUCTION STATISTICS
ERROR LOG
USER DEFINED SYNERGIC DATA
LIMIT EDITOR
STORE DELETE RECALL QUIT
GB
To Next Page
