12.2.2 Configuring a digital remote control
Without remote control adapter
When a CAN--bus remote control is connected, the configuration for DIGITAL OP is
made automatic.
With remote control adapter
When using a digital remote control, specify which type of remote control is being
used:
If you move the cursor to the line for DIGITAL OPERATED and press ENTER, you
will call up a list from which you can select an option.
BINARY CODED
5--PROG
S 32--program device BINARY CODED
S 5--program device or a welding gun with a 3--program choice 5--PROG
12.2.3 Configuring an analogue remote control
Without remote control adapter
When a CAN--bus remote control is connected, the configuration for ANALOG 1 and
ANALOG 2 is made automatic. You can not change the configuration.
With remote control adapter
When using an analogue remote control, you can use the controller to specify which
potentiometer(s) you want to use (maximum 2).
The potentiometers are designated ANALOG 1 and ANALOG 2 in the controller, and
these refer to the parameters defined for the welding process in each case, e.g.
voltage (ANALOG 1) and wire feed (ANALOG 2) for MIG/MAG.
If you move the cursor to the line for ANALOG 1 and
press ENTER, a list appears.
NONE
VOLTAGE
You can now select whether potentiometer ANALOG 1 is to be used (VOLTAGE) or
not (NONE).
Select the line for VOLTAGE and press ENTER
If you move the cursor to the line for ANALOG 2 and
press ENTER, a list appears.
NONE
WIRE SPEED
You can now select whether potentiometer ANALOG 2 is to be used (WIRE SPEED)
or not (NONE).
Select the line for WIRE SPEED and press ENTER
All remote control configurations apply to any wire feeders that are connected.
If you deselect ANALOG 1, this will apply for both wire feeders if you are using
double wire feeders.
