12.5 General defaults
Main menu ----> Auxiliary function menu ----> Configuration menu ----> General
defaults
12.5.1 Fast mode soft keys
The soft keys ”WELD DATA 1” – ”WELD DATA 4” are visible in the fast mode menu.
These are configured as follows:
FAST MODE SO FT KEYS
Move the cursor to the line
with soft key numbers.
The keys are numbered
1--4, from left to right.
Select the desired key by
entering its number using
the plus/minus keys.
SOFT KEY NUMBER : 1
ASSOCIATED WELD DATA: 1
" DIP/SPRAY, Fe, CO2, 1.2 mm
QUIT
Then scroll down using the arrow down key to the line for ”ASSOCIATED WELD
DATA”. Here you can browse among the weld data settings that are stored in the
welding data memory. Select the desired weld data number using the plus/minus
keys.
12.5.2 Double start sources
When this option is activated (ON) you can start MIG/MAG welding both from the
wire feed unit’s start input and from the power source’s TIG--start input and vice
versa. When welding is started from a start signal input it must be stopped from the
same input.
12.5.3 Panel remote enable
Ordinarily you cannot make settings using the pushbuttons when the panel is in
remote control mode. When “panel remote enable.” is ON the current/wire feed or
voltage can be set using the control panel and remote control.
When “panel remote enable.” is used in combination with limits, machine usage can
be limited to a specific setting range. This applies to the following settings: wire feed
and voltage for MIG/MAG welding, current setting for MMA and TIG welding, pulse
current with pulsed TIG.
