ESAB Aristo U8 User Manual

-- 8 --
bi09dinte
1.3 Display
ESAB Mig
PROCESS: MIG/MAG
METHOD: DIP / SPRAY
WIRE TYPE: Fe
SHIELDING GAS: CO2
WIRE DIMENSION: 1.2 MM
AUXILIARY FUNCTIONS
SET MEASURE MEMORY
FAST
MODE
ENTER
The cursor
The cursor in the controller appears a s a shaded field around the text, which has the
effect of turning the selected text white. T he cursor appears in bold text in the
instruction m anual.
Text boxes
At the bottom of the display there are five boxes containing text that explains the
current functions of the five keys in the line directly below them.
Saver mode
To extend the life of the backlit display, it is switched off after three minutes if there is
no activity.
1.3.1 Symbo ls in th e disp lay
A The selected weld data set
B Recalled memory position number
C More information is available on the next
page
D Select the plus/minus buttons marked
with * to increase or decrease the
parameter value
E Select the plus/minus buttons marked
with # to increase or decrease the
parameter value
GB

ESAB Aristo U8 Specifications

General

Category	Welding Accessories
Type	Wire feeder
Display	Digital
Wire Feed Speed Range	0.5 - 25 m/min
Input Current	16 A
Wire Diameter Range	0.6 - 1.6 mm
