3 MIG/MAG WELDING
Main menu ----> Process
The arc in MIG/MAG welding m elts a filler wire (the electrode) that is continuously
fed into the weld, with the molten zone being protected by a shielding gas.
Pulsing is used to affect the transfer of the droplets from the arc so that it is stable
and does not produce spray, even with low weld data.
The table on page 68 shows the wire diameters that can be selected for MIG/MAG
welding with DIP/SPRAY.
The table on page 69 shows the wire diameters that can be selected for MIG/MAG
welding with PULSE.
3.1 Settings in the weld data setting menu
3.1.1 MIG/MAG welding with dip/spray
Settings Setting range In steps
of:
Values
after reset
Synergic
depend -
ent
Adjust--
able in
synergic
Voltage 8--60 0.25 (dis-
played to
one deci-
mal place)
synergic
deviation
¦ 0
x x
Wire speed ** 0.8 -- 25.0 m/min 0.1 m/min 5m/min x
Inductance 0 -- 100% 1 80% x x
Control type 1--12 1 4 x
Synergic mode* OFF or ON -- ON * -- --
Gas pre-- flow 0.1 -- 25 s 0.1 s 0.1 s x
Creep start NO or YES -- NO x
Hot start NO or YES -- NO x
Hot start time 0--10s 0.1 s 1.5 s x
Hot start wire speed Complete wire feed
range
0.1 m/min 2m/min x
Hot start voltage Complete voltage
range
0.25 V 4.5 V x
Crater filling NO or YES -- NO x
Crater fill time 0--10s 0.1 s 1.5 s x
Final crater filling wire
speed
1.5 m/min to current
wire feed speed
0.1 m/min 3m/min x
Final crater filling
voltage
8 V to actual voltage 0.25 V 18 V x
Pinch off pulse 10 -- 120% 1 60% x
Burn back time 0--1s 0.01 s 0.12 s x
Gas post--flow 0.1 -- 25 s 0.1 s 0.1 s x
Limits 1--50 -- -- -- --
Spot welding OFF or ON -- OFF x
Spot welding time 0--25s 0,1 s 0,5 s x
*) Default synergic line: solid wire (Fe), shielding gas CO
2
with wire 1.2 mm.
**)The setting range is dependent on the wire feed unit used.
