2.2 Menu structure
AUXILIAR Y FUNCTIONS SET MEASURE MEMORY FAST MODE
STOP DATA COPY
START DATA RECALL
DELETE
STORE
*) This is the start image (measure image) that is shown when you switch on the machine.
The sample image above is for MIG/MAG --welding with synergic mode.
AUXILIAR Y FUNC-
TIONS
auxiliary functions
menu
S see page 35
SET weld data setting menu S for MIG/MAG welding, see page 15
S for MMA welding, see page 21
S for TIG welding, see page 22
S for carbon, arc air, see page 26
S for MIG Superpulse, see page 28
MEASURE measure image S see page 12
MEMORY Memory management
menu
S ses page 30
FAST MODE Fast mode menu S see page 51
GB
