This is how to enter various limits:
GENERAL DEFAULTS -- LIMIT EDITOR
Select the number for which
you want to enter limits (2)
and press ENTER.
Select the process to which
it applies (MIG/MAG) and
press ENTER
LIMIT NUMBER: 1
PROCESS: --
DELETE QUIT ENTER
The following menu appears:
GENERAL DEFAULTS -- LIMIT EDITOR
Move the cursor to the line
for VOLTAGE. Use the
#plus/minus key for max.
voltage setting and the
*plus/minus key for min.
voltage setting.
LIMIT NUMBER: 1
PROCESS: MIG/MAG
VOLTAGE: MAX 60.0 V
MIN 8.0 V
WIRE SPEED: . MAX 25.0 m/min
MIN 1.5 m/min
AUTO DELETE QUIT
Follow the same procedure for WIRE SPEED.
TIP: If you want to set limits at +/--10% from actual data, press AUTO.
When you have selected a limit number, the limits for the operator are not locked
until you set the wire feed speed/current and voltage within the limit values.
18 OTHER INFORMATION
18.1 ESAB Logic Pump (Water lock)
U8 works together with the ELP function on the wire feed unit/power source, see the
Instruction Manual for the wire feed unit/power source for further information.
