8.2 Store
If the weld data memory is empty, the following screen appears in the display.
MEMORY FUNCTIONS -- STORED DATA SETS
We will now store a set of
weld data. We will give it
memory position 5. Press
the STORE key.
* NO STORED DATA SETS *
STORE QUIT
The following screen appears in the display.
STORE IN DATA NO. 1
If you press ENTER here,
the data set is saved
as number 1, as indicated
in the top line of the display.
QUIT ENTER
By scrolling using the plus/minus keys, you can define which memory position the data set will have.
The figure shown in the top line of the display is the first empty position that was
located in the memory.
STORE IN DATA NO. 5
Scroll forwards to number 5
using the plus/minus
keys. Press ENT ER.
QUIT ENTER
The data set has now been stored as number 5. At the bottom of the display you can
see parts of the content of data set number 5.
