EtherWAN EW50 User Manual

EW50 Industrial LTE Cellular Gateway
14
1.5.4 Product Information for CE RED Requirements
The following product information required to be presented in product User Manual for latest CE RED
requirements.
2
(1) Frequency Band & Maximum Power
1.a Frequency Band for Cellular Connection
Band number
Operating Frequency
Max output power
LTE FDD BAND 1
Uplink: 1920-1980 MHz
Downlink: 2110-2170 MHz
23 ±2.7 dBm
LTE FDD BAND 3
Uplink: 1710-1785 MHz
Downlink: 1805-1880 MHz
LTE FDD BAND 7
Uplink: 2500-2570 MHz
Downlink: 2620-2690 MHz
LTE FDD BAND 8
Uplink: 880-915 MHz
Downlink: 925-960 MHz
LTE FDD BAND 20
Uplink: 832-862 MHz
Downlink: 791-821 MHz
WCDMA BAND 1
Uplink: 1920-1980 MHz
Downlink: 2110-2170 MHz
24 +1/-3 dBm
WCDMA BAND 8
Uplink: 880-915 MHz
Downlink: 925-960 MHz
E-GSM
Uplink: 880-915 MHz
Downlink: 925-960 MHz
33 ±2 dBm
DCS
Uplink: 1710-1785 MHz
Downlink: 1805-1880 MHz
30 ±2 dBm
(2) RF Exposure Statements
The antenna of the product, under normal conditions, should be at least 20 cm away from the body of the
user.
2
The information presented in this section is ONLY valid for the EU/EFTA regional version. For non-CE/EFTA versions, refer to the
corresponding product specification.
