EtherWAN EW50 User Manual

EW50 Industrial LTE Cellular Gateway
205
2. 5s is set by default
Enter the ping time interval in seconds.
Value Range: 5 ~ 999 seconds.
Remote Subnet
Required setting
Specify the remote subnet for this GRE tunnel.
The Remote Subnet format must be IP address/netmask (e.g. 10.0.0.2/24).
It is for the Intranet of GRE server peer. At GRE client peer, the packets whose
destination is in the dedicated subnet will be transferred via the GRE tunnel.
Others will be transferred based on current routing policy of the security
gateway at GRE client peer.
If 0.0.0.0/0 is entered in the Remote Subnet field, it will be treated as a default
gateway setting for the GRE client peer, and all packets, including the Internet
accessing of GRE client peers, will go through the established GRE tunnel. That
means the remote GRE server peer controls the flow of any packets from the
GRE client peer.
DMVPN Spoke
Unchecked by default
Specify whether the gateway will support DMVPN Spoke for this GRE tunnel.
Check Enable box to enable DMVPN Spoke.
IPSec Pre-shared
Key
Required setting
Enter a DMVPN spoke authentication Pre-shared Key (8~32 characters).
Note: Pre-shared Key is available only when DMVPN Spoke is enabled.
IPSec NAT Traversal
Unchecked by default
Check Enable box to enable NAT-Traversal.
Note: IPsec NAT Traversal will not be available when DMVPN is not enabled.
IPSec Encapsulation
Mode
Unchecked by default
Specify IPsec Encapsulation Mode from the dropdown box. There are Transport
mode and Tunnel mode supported.
Note: IPsec Encapsulation Mode will not be available when DMVPN is not
enabled.
Tunnel
Unchecked by default
Check Enable box to enable this GRE tunnel.
Save
N/A
Click Save button to save the settings.
Undo
N/A
Click Undo button to cancel the settings.
Back
N/A
Click Back button to return to the previous page.
