EtherWAN EW50 User Manual

EW50 Industrial LTE Cellular Gateway
268
Data Usage Setting
Go to Service > Cellular Toolkit > Data Usage tab.
To configure Data Usage, you need to know the billing start date, bill period, and data limit for your data plan.
Create / Edit 3G/4G Data Usage Profile
When the Add button is applied, 3G/4G Data Usage Profile Configuration screen will appear. You can create
up to four data usage profiles, one profile for each SIM card used in the Gateway.
3G/4G Data Usage Profile Configuration
Item Setting
Value setting
Description
SIM Select
3G/4G-1 and SIM A by
default.
Choose a cellular interface (3G/4G-1 or 3G/4G-2), and a SIM card bound to the
selected cellular interface to configure its data usage profile.
Note: 3G/4G-2 is only available for products with dual cellular modules.
Carrier Name
Optional item.
Fill in the Carrier Name for the selected SIM card for identification.
Cycle Period
Days by default
The three types of cycle period are Days, Weekly and Monthly.
Days: For per Days cycle periods, you must further specify the number of days in the
second box. Value Range: 1 ~ 90 days.
Weekly, Monthly: The cycle period is one week or one month.
Start Date
N/A
Specify the date to start measuring network traffic.
Don’t select a day in the past. This will cause traffic statistics to be incorrect.
Data Limitation
N/A
Specify the allowable data limitation for the defined cycle period.
Connection
Restrict
Un-Checked by default.
Check the Enable box to activate the connection restriction function.
During the specified cycle period, if the actual data usage exceeds the allowable data
limitation, the cellular connection will be forced to disconnect.
Enable
Un-Checked by default.
Check the Enable box to activate the data usage profile.
