MAINTENANCE MANUAL
ERTC022-10-AS
Effectivity: All
24-60
Page 24-43
2017-12-22
Edition 2 | Rev. 1
Designation Value (A) Description
ACCU
50 Circuit breaker of battery
GEN - REF.
1 Circuit breaker of generator excitation
GEN
25 Circuit breaker of generator
AUX. GEN
30 Circuit breaker of auxiliary generator
AUX. GEN. FIELD
5 Circuit breaker of auxiliary generator excitation
BATTERY G3X
5 Circuit breaker of backup battery IBBS-12v-3ah
BEACONS
7,5 Circuit breaker of strobe lights
POS. LIGHTS
2 Circuit breaker of position lights
LDG LIGHT
4 Circuit breaker of landing light
FUEL PUMP
3 Circuit breaker of electrical fuel pump
PFD
5 Circuit breaker of MFD display
MFD
5 Circuit breaker of PFD display
ADAHRS 1
2 Circuit breaker of main ADAHRS unit
ADAHRS 2
2 Circuit breaker of backup ADAHRS unit
EMS
2 Circuit breaker of EIS unit
Table 24-9 Left panel of circuit breakers – Garmin G3X system, typical layout (from the right)
Designation
Value (A)
Description
SIGNAL.
1 Circuit breaker of signalization
STALL WARNING
1 Circuit breaker of stall warning system
TRIM
1 Circuit breaker of pitch trim
COMM
10 Circuit breaker of transceiver
NAV
4 Circuit breaker of navigation equipment
XPDR
5 Circuit breaker of transponder
ALT. ENCOD.
2 Circuit breaker of altitude encoder
Table 24-10 Right panel of circuit breakers – Garmin G3X system, typical layout (from the left)
CAUTION
DON´T USE THE CIRCUIT BREAKERS FOR STANDARD
SWITCHING OFF THE ELECTRICAL APPLIANCES.
