MAINTENANCE MANUAL
Effectivity: All
Page 33-27
Edition 2 | Rev. 1
1 Switch the electrical network and the switch TAXI LIGHT on.
2 Use the adjusting screws (8; 12) to set vertical and horizontal position of the
light so that the cone of light falls on the centre of the crosshair on the test
jig.
3 Repeat steps (d) to (g).
4 Switch the switch TAXI LIGHT and the electrical network off.
(h) Install the cover (16) and the light cover W8R (Fig. 06-2) again.
