MAINTENANCE MANUAL
Efectivity: All
Page 06-9
Edition 2 | Rev. 1
Designation Description
F1 Propeller spinner
F2 Engine upper cowling
F2a Cap for oil level check
F2b Cap for coolant level check
F3 Engine lower cowling
F4 Upper cover of the fuselage front section
F5 Inspection cap on the fuselage lower part
F6 Cover of the rear part of the fuselage
F7 Cover for access to the Pitot-static system drain sumps
F8 Rocket cover (if the emergency parachute system is installed; riveted)
F9 Cable cover (if the emergency parachute system is installed; riveted)
F10 Cover for access to the Pitot-static system drain sump (only if two Pitot-static tubes
installed)
W1L / W1R Fairing between wing and fuselage
W2L / W2R Fuel tank caps
W3L / W3R Cover on the wing lower surface for access to the aileron control rods
W4L / W4R Cover on the wingtip lower surface for access to the venting
hose of the fuel tank
W5L / W5R Cover on the wing lower surface for access to the venting hose of the fuel tank
W6L / W6R Cover on the wing lower surface for access to connection of the fuel tanks to the
fuel system in the airplane fuselage
W7L Cover on the wing lower surface for access to hoses of the Pitot-static system
W8L Cover of the landing / taxi light
W8R Cover of the taxi light
IN1L / IN1R Cover of the control rod in the cockpit
IN2L / IN2R Cover of the main landing gear hinge
IN3 Floor of the baggage compartment
IN4 Cover for access to ADAHRS (if the Dynon SkyView system or Garmin G3X system
is installed)
IN5 Cover for access to the antenna installation
IN6L / IN6R Cover for access to the fuel cock
U1 Aerodynamic fairing of the nose wheel
U2L / U2R Aerodynamic fairings of the main landing gear wheels
