XTP CrossPoint Series • Programming Guide 106
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Outputs on XTP CP 4o [XTP], XTP CP 4o 4K [XTP], and XTP CP 4o Fiber 4K Boards (continued)
Ethernet serial port insert parameters (continued)
Set UART starting point
EX2!
MD
}
Pmd
X2!]
Sets the initial (lowest) port number for the
range of numbers assigned to the serial
port and UARTs.
NOTE: Output insert port 1 is 32 positions from
X2!
for both 1600 and 3200 matrix sizes.
Read UART starting point
E
MD
} X2!]
Outputs on XTP CP 4o [XTP] and XTP CP 4o 4K [XTP] Boards
XTP power
ATTENTION:
• Power over XTP (PoX) is intended for indoors use only. No part of a network that uses PoX can be routed outdoors.
• PoX est destiné à une utilisation en intérieur uniquement. Aucune partie d’un réseau qui utilise PoX ne peut être routée en extérieur.
NOTES:
• PoX is supplied by the matrix switcher 48 V power supply.
• XTP CrossPoint 1600:
• Can power up to 28 total (input and output) endpoints at up to 364 watts.
• Is available with optional 48 V power supply redundancy.
• XTP CrossPoint 3200:
• Can power up to 24 total (input and output) endpoints at up to 312 watts.
• No 48 V power supply redundancy is available.
Enable or disable power to output
endpoint and report status
E
O
X@
*
X2@
POEC
}
PoecO
X@
*
X2@
*
X2#
*
X2$]
Enable or disable (
X2@
) remote power on
output
X@
. The endpoint is requesting
X2#
watts and the power status is
X2$
.
View output power status
E
O
X@
POEC
} X2@
*
X2#
*
X2$]
Enable or disable output power and
report status, all outputs
E
O
X2@
*POEC
}
PoecO00*
X2@
1
X2@
2
...
X2@
n
]
Each
X2@
is the enable or disable status of
an output, starting at 1. n is 16 or 32.
View all output power status
E
OPOEC
} X2@
1
X2@
2
X2@
3
...
X2@
n
]
View XTP power usage
E
TPOEC
} X2%
*
X2^]
Show PoX wattage applied and the
status of the 48 V power supply.
NOTE: X@ = Output number 01 – 16 or 32
X2! = UART starting point The starting point (X2!) is the rear panel RS-232/RS-422 port.
The next position (X2!
+1
) is not used.
For the XTP CrossPoint 1600, X2!
+2
through X2!
+17
are XTP inputs.
For the XTP CrossPoint 3200, X2!
+2
through X2!
+33
are XTP inputs.
For the XTP CrossPoint 1600 —
X2!
+18
through
X2!
+34
are XTP outputs.
For the XTP CrossPoint 3200 —
X2!
+34
through
X2!
+65
are XTP outputs.
Default values: 1999 = Rear panel remote RS-232/RS-422 port
2001 through 2016 (XTP CrossPoint 1600) = Inputs
2001 through 2032 (XTP CrossPoint 3200) = Inputs
2033 through 2048 (XTP CrossPoint 1600) = Output 1 through 16
2033 through 2064 (XTP CrossPoint 3200) = Output 1 through 32
X2@ = Enable or disable for power 0 = Disable (default) 1 = Enable
X2# = Amount of power requested 00 or 13 (watts)
X2$ = Power status 0 = Unpowered endpoint 2 = Power available but disabled 4 = Fault
1 = Power provided to endpoint 3 = No power available, but enabled
X2% = Wattage Power usage in 0.1 watt increments. Example: 260 = 26.0 watts
X2^ = Power supply status 0 = Ok 1 = Not Ok
