Extron electronics XTP CrossPoint1600 - Symbol Definitions

XTP CrossPoint Series • Programming Guide 83
Output boards Output endpoints
Command
family
XTP
XTP 4K
Fiber 4K HDMI
HDMI
DVI Pro Analog
audio
XTP R HDMI
XTP R HD 4K
XTP R HWP 201
XTP R HWP 201 4K
XTP FR HD 4K
XTP SR HDMI
XTP SR HD 4K
XTP SFR HD 4K
Audio routing selections
N/A N/A Page 103 Page 103 N/A Page 107 Page 109
HDCP status
N/A Page 103 Page 103 Page 103 N/A Page 108 Page 109
Captive screw and Ethernet
serial port insertions
Page 105 Page 105 N/A N/A N/A N/A N/A
Ethernet serial port insert
parameters
Page 105 Page 105 N/A N/A N/A N/A N/A
XTP power Page 106 N/A N/A N/A N/A N/A N/A
Video mutes
N/A Page 103 Page 103 Page 103 N/A Page 107 Page 108
Output audio volume
N/A N/A Page 104 Page 104 Page 104 Page 107 Page 109
Audio mutes
N/A N/A Page 105 Page 105 Page 105 Page 107 Page 109
Relay controls
Page 108 Page 110
View video and audio mutes
N/A Page 105 Page 105 Page 105 Page 105 Page 108 Page 110
Symbol definitions
]
= Carriage return and line feed
}
=
Carriage return (| pipe can be used interchangeably)
•
=
Space character
E
=
Escape key (W can be used interchangeably)
X!
=
Input number (for ties) 00 to 16 or 32 (00 = untied)
X@
=
Output number 01 to 16 or 32
X#
=
Global preset number 00 to 32 (00 = current configuration, applies to view
ties command only)
X$
=
EDID value See the table beginning on page 89.
X%
=
Input signal status 0 = no signal detected
1 = sync detected
X^
=
Input number (for other
functions than ties)
01 to 16 or 32 (also addressed input on matrix
switcher endpoints [ sub-inputs])
X&
=
Audio gain 00 to 24 (1 dB steps)
X*
=
Numeric dB value -18 to +24 (43 steps of gain or attenuation) (0 dB =
default)
X(
=
Audio attenuation 1 to 18 (1 dB steps)
X1)
=
Resolution and rate for
black screen
2 = 1280x720p @ 50 Hz
4 = 1280x720p @ 60 Hz
6 = 1920x1080p @ 60 Hz
X1!
=
Input audio source 0 = auto (see the example on page 91)
1 = HDMI (de-embedded digital audio) (default)
2 = analog 2-channel audio
X1@
=
HDCP authorized device 0 = off
1 = on (default)
X1#
=
HDCP status (for inputs) 0 = no source device connected
1 = source connected is HDCP-compliant
2 = source connected is not HDCP-compliant
X1$
=
Captive screw or UART 0 = captive screw RS-232 insert (default)
1 = Ethernet RS-232 insert (UART)
