XTP CrossPoint Series • Operation 32
Control Buttons
NOTE: See Front Panel Operations, beginning on page 35, for detailed
descriptions of the following operations.
Primary functions
Action Save changes Select Preset mode Select View mode Cancel or Escape
Indication Blink: Save needed Blink: Save preset
Lit: Recall preset
View mode
selected
Blinks once
ENTER PRESET
VIEW
ESC
Secondary functions
Port
configuration
Action 1 Select Configuration mode.
Action 2 Select 9600 baud Select 19200 baud Select 38400 baud Select 115200
baud
Indication Blink: 9600 baud Blink: 19200 baud Blink: 38400 baud Blink: 115200 baud
Front panel
locks
Action 1 Select Lock mode 1 or toggle between
mode 2 and mode 1.
Action 2 Select Lock mode 2 or toggle between mode 0 and mode 2.
Audio Action In Audio mode,
decrease input
level or output
volume.
In Audio mode,
increase input
level or output
volume.
C
Enter button (see figure 28 on page 29 or figure 29 on page 30) — Enter has
two primary () and two secondary functions (•):
 Saves configuration or preset changes that you make on the front panel. To create a
simple configuration:
• Specify video, audio, or both (see I/O buttons [
G
] and [
H
]).
• Press the desired input button (
A
).
• Press the desired output button or buttons (
B
).
• Press the Enter button.
 Indicates that a potential tie has been created but not saved.
• With the Preset, View, and Esc buttons, selects Serial Port Configuration mode.
• Selects 9600 baud for the rear panel Remote port in Serial Port Configuration mode
and indicates the selection.
D
Preset button (see figure 28 or figure 29) — Preset has two primary () and three
secondary functions (•):
 Activates Save Preset mode to save a configuration as a preset and Recall Preset
mode to activate a previously-defined preset.
 Blinks when Save Preset mode is active and lights steadily when Recall Preset mode
is active.
• With the Enter, View, and Esc buttons, selects Serial Port Configuration mode.
• Selects 19200 baud for the rear panel Remote port in Serial Port Configuration mode
and indicates the selection.
• With the View and Esc buttons, selects front panel security Lock mode 2 or toggles
between mode 0 (unlocked) and mode 2.
