XTP CrossPoint Series • Operation 33
E
View (
<
) button (see figure 28 on page 29 or figure 29 on page 30) — The View
(
<
) button has one primary function () and six secondary functions (•):
 Select and indicate View-only mode, which displays the current configuration.
NOTE: View-only mode also provides a way to mute and unmute the outputs.
• Decreases the audio level of the selected analog input.
• Decreases the volume of the selected analog output.
• With the Enter, Preset, and Esc buttons, selects Serial Port Configuration mode.
• Selects 38400 baud for the rear panel Remote port in Serial Port Configuration
mode, and indicates the selection.
• With the Preset button and Esc button, selects between front panel locks (Lock
mode 2 and Lock mode 0).
• With the Esc button, selects between front panel locks (Lock mode 2 and Lock
mode 1).
F
Esc (
>
) button (see figure 28 or figure 29) — The Esc (
>
) button has two primary
functions () and six secondary functions (•):
 Cancels operations or selections in progress and resets the front panel button
indicators.
 Blinks once to indicate that the escape function has been activated.
• Increases the audio level of the selected analog input.
• Increases the volume of the selected analog output.
• With the Enter, Preset, and View buttons, selects Serial Port Configuration mode.
• Selects 115200 baud for the rear panel Remote port in Serial Port Configuration
mode and indicates the selection.
• With the Preset button and View button, selects between front panel locks (Lock
mode 2 and Lock mode 0).
• With the View button, selects between front panel locks (Lock mode 2 and Lock
mode 1).
