XTP CrossPoint Series • Introduction 4
Input and Output Board and Signal Types
The XTP CrossPoint Series matrix switchers are assembled from user-installed and
hot-swappable input and output boards. This section details the signal types processed by
each board and the function of boards.
The boards have a primary signal type that is identified by the name of the board and used
as the subsections of the Primary signal type, by board section starting on the next
page. Most boards have secondary signal types that are used as the subsections of the
Secondary signal type on page 7.
See the tables below and the following subsections for an explanation of the various input
and output board capabilities.
Input Board Signal Type Table
Signal Type
Input Board XTP Fiber HDMI 4K HDMI DVI Pro 3G/HD-SDI/SDI Analog Video Remote Power RS-232 Inserts Dedicated UARTs Analog Audio
XTP CP 4i and XTP CP 4i 4K • • • •
XTP CP 4i Fiber 4K • • •
XTP II CP 4i HD 4K PLUS • •
XTP CP 4i HDMI • •
XTP CP 4i HDMI DMA • •
XTP CP 4i DVI Pro • •
XTP CP 4i 3G-SDI • •
XTP CP 4i VGA • •
Output Board Signal Type Table
Output Board XTP Fiber HDMi 4K HDMI DVI Pro Remote Power RS-232 Inserts Dedicated UARTs Analog Audio
XTP CP 4o and XTP CP 4o 4K • • • •
XTP CP 4o Fiber 4K • • •
XTP CP 4o HD 4K PLUS • •
XTP CP 4o HDMI • •
XTP CP 4o DVI Pro • •
XTP CP 4o SA •
